MC-2500T
Stationary Tub Grinder (Wood crusher)
High functionality
and
efficiency with a low price
Reasonable Price
The MC-2500T is stationary tub grinder.
By removing the crawler system, MC-2500T maintains the same capability and quality of the MC-2000VA.
Affordability is key with the removal of the crawler system, resulting in a reliable, fixed unit.
 |
 |
Easy Maintenance
A simple structure makes easy maintenance (inspection, repair, parts replacement), the same as other models. In addition, easy operability by a simple lever.
 |
 |
Two types of cutter drums on your needs
MC-2500T is compatible with new cutter blade (right figure).
The new cutter blade has more capability compared to the triangle blade type (left figure).
|
Triangle blade |
Cutter blade (optional) |
Dimension / Specification
| MC-2500T | |
| Machine Weight | 8,600 kg |
| Engine | MITSUBISHI 6D16-TLE2A Tier 2, EU Stage Ⅱ |
| Rated Output | 140 kW / 2,200 rpm |
| Piston Displacement | 7,540 cc |
| Overall Length | 5,055 mm |
| Overall Width | 2,400 mm |
| Overall Height | 2,535 mm |
| Crawler Width | ー |
| Belt conveyor Width × Length | 620×3,140±250 mm |
| Tub Depth × Opening inside diameter | 1,300×1,800 mm |
| Travel Speed | ー |
| Fuel Tank Capacity | 172 ℓ |
